Key Information

• Dimensions — 382(L) x 310(W) x 310(H)mm
• 18 Litre Capacity — Ideal for domestic heating systems
• Nitrogen-Filled Vessel — Factory pre-charged to 1.5 bar
• Non-Replaceable Diaphragm — Synthetic rubber membrane for reliability
• Pressure-Tight Crimped Collar — Ensures secure sealing
• Grey Powder Epoxy Finish — Corrosion-resistant coating
• Max Flow Operating Temperature: 120°C — Suitable for high temperature systems
• Max Vessel Operating Temperature: 70°C — Designed for heating applications
• Test Pressure: 1.5 x Max Working Pressure — Built for durability
• Low Gas Permeability — Helps maintain stable pressure
• Glycol Resistant — Compatible with ethylene and propylene glycol mixtures
• Manufactured to BS EN 13831:2007 — Meets industry standards
• Pressure Equipment Directive Tested — Reliable and compliant
• 5-Year Guarantee — Long-term peace of mind

What's Included

• 1 x Altecnic Reflex 18L Heating Expansion Vessel

The Altecnic Reflex 18L Heating Expansion Vessel is designed to maintain stable pressure in sealed heating systems, helping to protect components and ensure efficient operation. Suitable for a wide range of domestic and light commercial applications, this compact 18 litre vessel provides dependable performance and long-term reliability.

Durable Diaphragm Design

The vessel features a non-replaceable synthetic rubber diaphragm that separates air and water, allowing for safe expansion as system temperatures rise. The diaphragm and vessel halves are secured with a crimped collar, ensuring a pressure-tight seal across the unit.

Nitrogen Pre-Charged for Consistent Performance

Supplied factory pre-charged to 1.5 bar with nitrogen, the vessel provides stable operation and reduced maintenance. Nitrogen filling helps minimise pressure fluctuations and improves long-term performance.

Robust Construction

Finished in a grey powder epoxy coating, the vessel is protected against corrosion and wear. It is designed to withstand demanding system conditions, including high temperatures and glycol mixtures.

Designed for Heating System Compatibility

The expansion vessel is suitable for flow temperatures up to 120°C and is resistant to ethylene and propylene glycol mixtures. It is manufactured in accordance with the Pressure Equipment Directive and meets BS EN 13831:2007 standards for closed expansion vessels.

Shop at PlumbNation

Maintain safe and stable system pressure with the Altecnic Reflex 18L Heating Expansion Vessel, available now at PlumbNation. A durable and reliable solution for sealed heating systems.
